PIR security detector wall IP44

90975
Saxby
90975
UOS: Each
Hide
Adjustable wall PIR sensor. Suitable for traditional and LED light fittings and works with multiple lights. IP44 rated for outdoor use.
  • Complete with built in PIR
  • Ambient Light: <10Lux~2000 Lux (adjustable)
  • Detection Distance:Max.12m(<24°C）
  • Detection Range:180°
  • Installation Height：1.8-2.5m
  • Power Source: 220~240V/AC 50/60Hz
  • Rated Load: Max.2000W (incandescent lamp)
  • Time delay: 10Sec-7Min (adjustable)
  • White abs plastic
  • Constructed from abs plastic
  • Shipment Carton Qty: 100
Login To Buy

Overview

  • IP44
  • Proj: 77mm H: 70mm W: 55mm
  • Class 2
  • Minimum load 1W
  • 2YR Warranty
  • Weight: 0.1 Kg

Specification

Colour Finish:
White abs plastic
IP Rating:
44
Operating Voltage:
220-240V
Commodity Code:
8536501990
Country Of Origin:
China

Documents

Specification

Ambient Light: <10Lux~2000 Lux (adjustable)
Detection Distance:Max.12m(<24°C）
Detection Range:180°
Installation Height：1.8-2.5m
Power Source: 220~240V/AC 50/60Hz
Rated Load: Max.2000W (incandescent lamp)
Time delay: 10Sec-7Min (adjustable)

  • Commodity Code: 8536501990
  • Country of Origin:


    • Technical Datasheet

    Dimensons

    Unpacked Height (mm):
    70
    Unpacked Width (mm):
    55
    Unpacked Depth (mm):
    No Depth

    Pack Quantities

    Package Pack Type:
    Retail carton
    Package EAN:
    5017588909750
    Packed Height (mm):
    7.9
    Packed Wid (mm):
    6
    Packed Depth (mm):
    7.5
    Packed Weight (kg):
    .12

    Case Quantities

    Outer Carton
    Outer Pack Type:
    Shipment carton
    Outer Qty:
    100
    Outer Height (mm):
    43
    Outer Width (mm):
    34
    Outer Depth (mm):
    32
    Outer Gross Weight (kg):
    13.1
